CRI 250 Set

₹ 25000.00

CRI 250 Set is a professional piezo injector tester used for advanced testing of piezoelectric diesel injectors, including resistance, capacitance, insulation, and dynamic lift measurement.

Quantity

Whatsapp
  • Description
  • Diagnostics
  • Packing List
  • Parameters
  • Special Function

CRI 250 Injector Tester is a specialized tool designed for deep-level testing of piezoelectric injectors used in modern diesel engines. Unlike basic testers that only check spray, this device analyzes the internal health of the piezo crystal stack, which is critical for injector performance.


It works by generating controlled voltage and pulse signals to simulate real engine conditions and allows technicians to evaluate injector behavior with high precision. The tool combines the functions of a multimeter, LCR meter, and injector driver in one compact unit.


This makes it highly useful for advanced diagnostics, injector refurbishment, and professional diesel workshops.

BOSCH PIEZO
SIEMENS / VDO PIEZO
DENSO PIEZO
DELPHI PIEZO

CUMMINS
CRDI SYSTEM (PIEZO INJECTOR VEHICLES)

    -> Used in:

  • High-end diesel cars (BMW, Audi, Mercedes, VW)
  • Advanced CRDI engines
  • Euro 4 / Euro 5 / Euro 6 vehicles
  • CRI 250 Main Unit
  • Power Cable
  • Piezo Injector Test Leads
  • Connector Set
  • Clip Cables
  • Fuse Set
  • User Manual
  • Working Voltage: AC 100V – 240V
  • Adjustable Drive Voltage: 0 – 178V
  • Frequency Range: 1 – 100 Hz
  • Pulse Width: 0 – 5000 µs
  • Injector Type: Piezoelectric only
  • Display: LCD screen
  • Control: Dual rotary knobs (Voltage & Mode)
  • Measurement Modes:
    • Resistance
    • Capacitance
    • Insulation
    • Dynamic Lift
    • Injection Test
  • Warranty: Approx. 1 Year (varies by seller)
  • Piezo crystal resistance measurement
  • Capacitance testing (very important for piezo health)
  • Insulation resistance testing
  • Dynamic lift (valve movement) measurement
  • Injector driving simulation (ECU signal simulation)
  • High-frequency stress testing
  • Advanced fault detection (weak / failing injectors)
